| Input working voltage range: | 16-60VDC |
| MPPT Tracking Range: | 22-55VDC |
| Max DC input voltage: | 60VDC |
| Max DC input current: | 14A*2 |
| Max input short-circuit current: | 20A*2 |
| Output peak power: | 800w |
| Operating ambient temperature: | -40'C to +65°C |
| Rated output voltage: | 230VAC |
| Rated AC Grid Frequency: | 50Hz/60Hz |
| Power factor: | >0.99 |
| Rated output current: | 3.47A |
| Peak efficiency: | 96% |
| Protection Class: | Class l |
| Protection Degree: | IP67 |
