| Input working voltage range | 16-60VDC |
| MPPT Tracking Range | 22-55VDC |
| Max DC input voltage | 60VDC |
| Max DC input current | 14A*2 |
| Max input short-circuit current | 20A*2 |
| Output peak power | 800W |
| Operating ambient temperature | -40'C to +65°C |
| Rated output voltage | 230VAC |
| Rated AC Grid Frequency | 50Hz/60Hz |
| Power factor | >0.99 |
| Rated output current | 3.47A |
| Peak efficiency | 96% |
| Protection Class | Class l |
| Protection Degree | lP67 |
